Animations in Svelte

Animations are more present than ever in our websites and applications. They can make them look and feel different if done right, engaging your users. In this post, we'll learn how animations can be used in Svelte, and how you can extend those that are shipped with the library.

Modules

Svelte ships a series of modules that will help us while creating animations. We'll explore each of these to understand what they do.

animate
easing
motion
transition

svelte/easing

This package contains a series of functions with equations to produce different easing curves Available curves are:

back
bounce
circ
cubic
elastic
expo
quad
quart
quint
sine

But you can create your custom function as long as it's a function that will accept 1 parameter varying from 0 to 1 (1 represents the total duration of the animation) and returns another value, also ranging from 0 to 1.

svelte/motion

Two functions are exported in this package: tweened and spring.

Both of them will return a reactive value, interpolating in-between values given a set of parameters.

Note that these functions do not necessarily animate anything visually, but rather, create a ramp between values. These values can then be displayed or assigned to something else, like CSS properties.

Both functions can interpolate numbers, dates, arrays, and objects. You can also provide a different function for interpolating values.

tweened

Let's initialize a new Svelte app to see how it works.

npm init vite

✔ Project name: · svelte-animations
✔ Select a framework: · svelte
✔ Select a variant: · svelte-ts

cd svelte-web-components
pnpm install //use the package manager you prefer
pnpm run dev

// remove default Counter component
rm src/lib/Counter.svelte

Clear the App.svelte component to contain only what we need now.

<script>
	// add imports here
</script>

<main>
</main>

<style>
  :root {
    font-family: -apple-system, BlinkMacSystemFont, 'Segoe UI', Roboto, Oxygen,
      Ubuntu, Cantarell, 'Open Sans', 'Helvetica Neue', sans-serif;
  }

  main {
    text-align: center;
    padding: 1em;
    margin: 0 auto;
  }

  :global(main > * + *)  {
    margin-top: 24px;
  }
</style>

I'll create a new component named Tasks.svelte inside the lib folder.

<script lang="ts">
  import { tweened } from 'svelte/motion';
  export let tasks: { id; title; date }[] = [];

  let selected;
  tasks = tasks.sort((a, b) => {
    if (a.date > b.date) {
      return 1;
    } else if (a.date === b.date) {
      return 0;
    } else {
      return -1;
    }
  });

  function pad(num) {
    if (num < 10) {
      return `0${num}`;
    }
    return num;
  }

  function getDate(date) {
    return date
      ? `${date.getFullYear()}/${pad(date.getMonth() + 1)}/${pad(
          date.getDate(),
        )}`
      : '';
  }

  function getTime(date) {
    return date ? `${pad(date.getHours())}:${pad(date.getMinutes())}` : '';
  }

  let now = new Date();
  let date = tweened(now, { duration: 500 });

  function selectTask(task) {
    selected = task.id;
    date.set(task.date);
  }
</script>

<div class="task-view">
  <div class="task-list">
    <h2>Next tasks</h2>
    <ul>
      {#each tasks as task}
        <li
          class={selected === task.id ? 'selected' : ''}
          on:click={() => selectTask(task)}
        >
          {task.title}
        </li>
      {/each}
    </ul>
  </div>
  <div class="task-details">
    <h2>When?</h2>
    {#if selected}
      <p>{getDate($date)}</p>
      <p>{getTime($date)}</p>
    {/if}
  </div>
</div>

<style>
  .task-view {
    display: flex;
    flex-direction: row;
    justify-content: space-between;
    width: 300px;
    border: 2px solid #4f4f4f;
    border-radius: 8px;
    padding: 16px;
  }
  li {
    padding: 4px 8px;
  }
  li.selected {
    background-color: lightcyan;
  }
  li:hover {
    background-color: lightgray;
  }
</style>

The component will receive a list of tasks with a title and date, and then we'll create a transition between these dates when clicking any of them. (Look at how we auto-subscribe to the reactive value, prepending the variable name with $)

Let's update the App to use this component.

<script lang="ts">
  import Tasks from './lib/Tasks.svelte';

  let tasks = [
    { id: 1, title: 'Meeting', date: new Date('2021-12-17T03:24:00') },
    { id: 2, title: 'Gym', date: new Date('2021-08-22T09:12:00') },
    { id: 3, title: 'Movie', date: new Date('2021-09-01T22:07:00') },
  ];
</script>

<main>
  <Tasks {tasks} />
</main>
<!-- ... -->

And the result looks like this: anim01

In this example we are animating the value, but we can also apply these changes to CSS properties.

Let's create another example that achieves this. (Tweened.svelte).

<script>
  import { tweened } from 'svelte/motion';
  import { cubicOut } from 'svelte/easing';

  const toColor = tweened([255, 0, 0], {
    duration: 2000,
    easing: cubicOut,
  });

  let loop = () =>
    toColor
      .set([255, 0, 0])
      .then(() => toColor.set([0, 255, 0]))
      .then(() => toColor.set([0, 0, 255]))
      .then(() => loop());
  loop();
</script>

<div style={'background-color:rgb(' + $toColor.join(',') + ')'} />

<style>
  div {
    display: block;
    width: 100px;
    height: 100px;
  }
</style>

Here, we created a single div, and use tweened to interpolate values of an array.

When we set the value using the set function, it will return a promise that resolves when the final value is reached (for our purposes, the animation has ended). Then, we trigger a new value using set again. We can see in action how we can interpolate array values.

We must remember to update our application

<script lang="ts">
// ...
  import Tweened from './lib/Tweened.svelte';
// ...
</script>

<main>
  <!-- ... -->
  <Tweened />
</main>

The possible parameters for tweened are: delay (time before starting), duration (in milliseconds), easing (one of the easing functions shown before), interpolate (a (from, to) => t => value) function

Spring

Spring works differently to transition a variable from one value to another. We can set three parameters: stiffness, damping, which will set how the spring behaves while settling in the final value, and precision, which will determine when the value is considered settled.

Let's create a new component named Spring.svelte

<script>
	import { spring } from 'svelte/motion';

	const number = spring(0,{
	stiffness: 0.1,
	damping: 0.08
});

function changeValueTo(newValue) {
	number.set(newValue)
}

function resetValue() {
	number.set(0, {hard:true})
}

</script>

<div>
	<span>{$number.toFixed(1)}</span>
	<button on:click={() => changeValueTo(10)}>To 10</button>
	<button on:click={() => changeValueTo(100)}>To 100</button>
	<button on:click={() => changeValueTo(1000)}>To 1000</button>
	<button	 on:click={() => resetValue()}>Reset</button>
</div>

<style>
	div {
		display: flex;
		flex-direction:column;
		max-width:300px;
	}
</style>

Our component has a number reactive value that will bounce when changed until finally settling in the desired result. The larger the distance to the target value, the more it will bounce.

We need to update our app to import the component.

<script lang="ts">
// ...
  import Spring from './lib/Spring.svelte';
// ...
</script>

<main>
  <!-- ... -->
  <Spring />
</main>

This is what the final result looks like. anim03

svelte/transition

A transition is a function with the following signature:

(node: HTMLElement, params: any) => {
	delay?: number,
	duration?: number,
	easing?: (t: number) => number,
	css?: (t: number, u: number) => string,
	tick?: (t: number, u: number) => void
}

The svelte/transition module includes a series of functions that will let us animate our DOM: blur, draw, fade, fly, scale, slide and crossfade(this last function returns two transition functions)

They are used with the transition, in, or out directives. Transition is executed when the element enters or leaves the DOM. Four events are available with this directive introstart, introend, outrostart, outroend they are triggered whenever the initial or final animations start and end.

The in and out directives work like transition, but they only act when either the element is added or removed.

Create a new component named Transition.svelte.

<script lang="ts">
  import { onDestroy, onMount } from 'svelte';
  import {
    blur,
    crossfade,
    draw,
    fade,
    fly,
    scale,
    slide,
  } from 'svelte/transition';

  let show = false;
  let interval;

  let [from, to] = crossfade({
    fallback: () => {
      return { css: (t, u) => 'color:red' };
    },
  });

  onMount(() => {
    interval = setInterval(() => {
      show = !show;
    }, 2000);
  })

  onDestroy(() => {
	if (interval) {
	  clearInterval(interval);
    }
  });
</script>

<div class="playground">
  <div class="transition-item">
    <svg
      fill="#ffffff"
      width="32"
      height="32"
      viewBox="0 0 16 16"
      xmlns="http://www.w3.org/2000/svg"
    >
      {#if show}
        <path
          in:draw={{ duration: 1500 }}
          d="M1.414213562373095 0 16 14.585786437626904 L14.585786437626904 16 L0 1.414213562373095"
        />
        <path
          in:draw={{ duration: 1500 }}
          d="M14.585786437626904 0 L16 1.414213562373095 L1.414213562373095 16 L0 14.585786437626904"
        />
      {/if}
    </svg>
  </div>
  <div class="transition-item teleport">
    <div>
      {#if show}
        <span in:from={{ key: 'a' }} out:to={{ key: 'a' }}>cross...</span>
      {/if}
    </div>
    <div>
      {#if !show}
        <span in:from={{ key: 'a' }} out:to={{ key: 'a' }}>...fade</span>
      {/if}
    </div>
  </div>

  {#if show}
    <div class="transition-item" transition:blur>
      <span>Blur</span>
    </div>
    <div class="transition-item" transition:fade>
      <span>Fade</span>
    </div>
    <div class="transition-item" transition:fly={{ x: 30 }}>
      <span>Fly</span>
    </div>
    <div class="transition-item" transition:scale={{ start: 10 }}>
      <span>Scale</span>
    </div>
    <div class="transition-item" transition:slide>
      <span>Slide</span>
    </div>
  {/if}
</div>

<style>
  .teleport {
    display: flex;
    flex-direction: row;
    justify-content: center;
    width: 200px;
    margin-left:auto;
    margin-right:auto;
    border: 2px solid #4f4f4f;
    border-radius: 8px;
    padding: 16px;

  }
  .teleport > div {
      width: 100px;
    }

  svg {
    height: 128px;
    width: 128px;
  }

  path {
    stroke: black;
  }

  .transition-item + .transition-item {
    margin-top: 40px;
  }
</style>

I've added all of the provided animations to this example, so you can play around with them. anim07

Custom transitions

We can create custom transitions by creating a function that accepts an HTML element, and a configuration object, and returns an object with the required properties.

We'll create a new function called skew.

export function skew(node: HTMLElement, {delay = 0, duration = 1000, easing = cubicInOut, deg = 45} = {}) {
        const style = getComputedStyle(node);
        const target_opacity = +style.opacity;
        const transform = style.transform === 'none' ? '' : style.transform;
        return {
            delay,
            duration,
            easing,
            css: (_t, u) => `
                transform: ${transform} skew(${deg * u}deg);
                opacity: ${target_opacity * _t}
            `
        };
}

delay, duration, and easing are pretty standard to all shipped functions, so we'll keep them the same for ease of use. The magic happens in our css property. Based on our parameters, we will add the skew transform. u is nothing but 1-_t, so in this case, we will start from deg (skew is applied) to 0 (no skew) when the element is shown. The opposite will happen when removed.

Let's test it by creating a new component. (Skew.svelte)

<script lang="ts">
  import { onDestroy, onMount } from 'svelte';
  import { skew } from './skew';

  export let skewOptions = {};

  let show = false;
  let interval;

  onMount(() => {
    interval = setInterval(() => {
      show = !show;
    }, 2000);
  });

  onDestroy(() => {
    if (interval) {
      clearInterval(interval);
    }
  });
</script>

<div class="playground">
  {#if show}
    <div class="transition-item" transition:skew={skewOptions}>
      <span>Skew</span>
    </div>
  {/if}
</div>

svelte/animate

This package exports a single function: flip. Animations are to be used with the animate directive.

Note that there is a requirement to use this directive. The element that uses the animate directive must be the immediate child of a keyed each block.

Animations are triggered when the elements of an each block are reordered.

The signature of an animation is:

(node: HTMLElement, { from: DOMRect, to: DOMRect } , params: any) => {
	delay?: number,
	duration?: number,
	easing?: (t: number) => number,
	css?: (t: number, u: number) => string,
	tick?: (t: number, u: number) => void
}

As you can see the signature is very similar to those of the transitions. We'll make use of this similarity later.

Create a new component to test what flip and the animate directive do.

<!-- Flip.svelte -->

<script lang="ts">
  import { flip } from 'svelte/animate';
  let things = [
    { id: 1, name: 'foo', ready: true },
    { id: 2, name: 'bar', ready: false },
    { id: 3, name: 'baz', ready: true },
    { id: 4, name: 'fizz', ready: false },
  ];
  let sortBy = { field: 'id', order: 'DESC' };

  let sortedThings = things;

  function sortById() {
    if (
      sortBy.field !== 'id' ||
      (sortBy.field === 'id' && sortBy.order === 'DESC')
    ) {
      sortedThings = things.sort((a, b) => {
        if (a.id > b.id) {
          return 1;
        } else if (a.id < b.id) {
          return -1;
        }
        return 0;
      });
      sortBy = { field: 'id', order: 'ASC' };
    } else {
      sortedThings = things.sort((a, b) => {
        if (a.id > b.id) {
          return -1;
        } else if (a.id < b.id) {
          return 1;
        }
        return 0;
      });
      sortBy = { field: 'id', order: 'DESC' };
    }
  }
  function sortByName() {
    if (
      sortBy.field !== 'name' ||
      (sortBy.field === 'name' && sortBy.order === 'DESC')
    ) {
      sortedThings = things.sort((a, b) => {
        if (a.name > b.name) {
          return 1;
        } else if (a.name < b.name) {
          return -1;
        }
        return 0;
      });
      sortBy = { field: 'name', order: 'ASC' };
    } else {
      sortedThings = things.sort((a, b) => {
        if (a.name > b.name) {
          return -1;
        } else if (a.name < b.name) {
          return 1;
        }
        return 0;
      });
      sortBy = { field: 'name', order: 'DESC' };
    }
  }
  function sortByReadyState() {
    if (
      sortBy.field !== 'ready' ||
      (sortBy.field === 'ready' && sortBy.order === 'DESC')
    ) {
      sortedThings = [
        ...sortedThings.filter((x) => x.ready),
        ...sortedThings.filter((x) => !x.ready),
      ];
      sortBy = { field: 'ready', order: 'ASC' };
    } else {
      sortedThings = [
        ...sortedThings.filter((x) => !x.ready),
        ...sortedThings.filter((x) => x.ready),
      ];
      sortBy = { field: 'ready', order: 'DESC' };
    }
  }
</script>

<div class="container">
  <table>
    <tr>
      <th on:click={sortById}>id</th>
      <th on:click={sortByName}>name</th>
      <th on:click={sortByReadyState}>ready</th>
    </tr>
    {#each sortedThings as thing (thing.id)}
      <tr animate:flip>
        <td>{thing.id}</td>
        <td>
          {thing.name}
        </td>
        <td><input type="checkbox" bind:checked={thing.ready} /></td>
      </tr>
    {/each}
  </table>
</div>

<style>
  td {
    width: 100px;
  }
  .container {
    width: 100vw;
    display: flex;
    flex-direction: row;
  }
  table,
  tr,
  td,
  th {
    border: 1px solid gray;
    border-collapse: collapse;
  }
  th {
    cursor: pointer;
  }
</style>

We created a table with 4 rows, and the ability to order rows by different properties.

The elements are inside a keyed each block (remember this is a requirement). One of the cool things about the animate directive is that only the items that change will be animated. The rest will remain like they were.

The result looks like this. anim10

extending and reusing animations with transitions

Because transitions and animations are so similar, we can use transitions to extend flip or create new animations.

animations from transitions

If we look at both types of functions, we can see that we are able to create a wrapper function to convert our transition into an animation.

export function toAnimation<T>(
  fn: (node: HTMLElement, params) => T,
): (node: HTMLElement, { from, to }, params) => T {
  return (node, _animations, params = {}) => {
    return fn(node, params);
  };
}

Then, we can convert one of our transitions, and apply it with the animate directive.

<!--AnimationFromTransition.svelte -->
<script>
  import { fade } from 'svelte/transition';
  import { toAnimation } from './toAnimation';

  let fadeAnimation = toAnimation(fade);

 // ... same as Flip.svelte
</script>

<div class="container">
  <table>
    <tr>
      <th on:click={sortById}>id</th>
      <th on:click={sortByName}>name</th>
      <th on:click={sortByReadyState}>ready</th>
    </tr>
    {#each sortedThings as thing (thing.id)}
      <tr animate:fadeAnimation={{ duration: 400 }}>
        <td>{thing.id}</td>
        <td>
          {thing.name}
        </td>
        <td><input type="checkbox" bind:checked={thing.ready} /></td>
      </tr>
    {/each}
  </table>
</div>

<style>
  /* same as Flip.svelte*/
</style>

Now, instead of moving, reordered elements fade in/out.

Extending flip

We can also extend the flip animation with transitions. I'll create a wrapper function again.

// extendFlip.ts

import { flip } from 'svelte/animate';
export function extendFlip(fn) {
  return (node, animations, params = {}) => {
    let flipRes = flip(node, animations, params);
    let transitionRes = fn(node, params);

    let getTransform = (str) => {
      let results = str.match(/transform: (.*);/);
      if (results && results.length) {
        return results[results.length - 1];
      }
      return '';
    };

    let mergeTransform = (css1, css2) => {
      return `transform: ${getTransform(css1)} ${getTransform(css2)};`;
    };

    return {
      ...flipRes,
      css: (t, u) =>
        `${transitionRes.css(t, u)}; ${mergeTransform(
          flipRes.css(t, u),
          transitionRes.css(t, u),
        )};`,
    };
  };
}

Our function will get the transition function, and merge the transform property it returns with the one from flip.

Now, let's look at a slightly modified version of the previous component:

<script>
  import { scale, blur } from 'svelte/transition';
  import { extendFlip } from './extendFlip';

  let flipAndBlur = extendFlip(blur);
  let flipAndScale = extendFlip(blur);

  let things = [
    { id: 1, name: 'foo', ready: true },
    { id: 2, name: 'bar', ready: false },
    { id: 3, name: 'baz', ready: true },
    { id: 4, name: 'fizz', ready: false },
  ];

  let sortBy = { field: 'id', order: 'DESC' };

  let sortedThings = things;

  function sortById() {
    if (
      sortBy.field !== 'id' ||
      (sortBy.field === 'id' && sortBy.order === 'DESC')
    ) {
      sortedThings = things.sort((a, b) => {
        if (a.id > b.id) {
          return 1;
        } else if (a.id < b.id) {
          return -1;
        }
        return 0;
      });
      sortBy = { field: 'id', order: 'ASC' };
    } else {
      sortedThings = things.sort((a, b) => {
        if (a.id > b.id) {
          return -1;
        } else if (a.id < b.id) {
          return 1;
        }
        return 0;
      });
      sortBy = { field: 'id', order: 'DESC' };
    }
  }
  function sortByName() {
    if (
      sortBy.field !== 'name' ||
      (sortBy.field === 'name' && sortBy.order === 'DESC')
    ) {
      sortedThings = things.sort((a, b) => {
        if (a.name > b.name) {
          return 1;
        } else if (a.name < b.name) {
          return -1;
        }
        return 0;
      });
      sortBy = { field: 'name', order: 'ASC' };
    } else {
      sortedThings = things.sort((a, b) => {
        if (a.name > b.name) {
          return -1;
        } else if (a.name < b.name) {
          return 1;
        }
        return 0;
      });
      sortBy = { field: 'name', order: 'DESC' };
    }
  }
  function sortByReadyState() {
    if (
      sortBy.field !== 'ready' ||
      (sortBy.field === 'ready' && sortBy.order === 'DESC')
    ) {
      sortedThings = [
        ...sortedThings.filter((x) => x.ready),
        ...sortedThings.filter((x) => !x.ready),
      ];
      sortBy = { field: 'ready', order: 'ASC' };
    } else {
      sortedThings = [
        ...sortedThings.filter((x) => !x.ready),
        ...sortedThings.filter((x) => x.ready),
      ];
      sortBy = { field: 'ready', order: 'DESC' };
    }
  }
</script>

<div class="container">
  <table>
    <tr>
      <th on:click={sortById}>id</th>
      <th on:click={sortByName}>name</th>
      <th on:click={sortByReadyState}>ready</th>
    </tr>
    {#each sortedThings as thing (thing.id)}
      <tr animate:flipAndBlur>
        <td>{thing.id}</td>
        <td>
          {thing.name}
        </td>
        <td><input type="checkbox" bind:checked={thing.ready} /></td>
      </tr>
    {/each}
  </table>
</div>

<style>
  td {
    width: 100px;
  }
  .container {
    width: 100vw;
    display: flex;
    flex-direction: row;
  }
  table,
  tr,
  td,
  th {
    border: 1px solid gray;
    border-collapse: collapse;
  }
  th {
    cursor: pointer;
  }
</style>

And the results:

Blur + flip anim12

Scale + flip anim13

Final words

Svelte did a great job making animations and transitions easy with their API. The provided functions work great in many scenarios.

I hope this blog post invites you to explore the API, extend what's already there, and share it with other users. These examples are available in this repo.

This Dot is a consultancy dedicated to guiding companies through their modernization and digital transformation journeys. Specializing in replatforming, modernizing, and launching new initiatives, we stand out by taking true ownership of your engineering projects.

We love helping teams with projects that have missed their deadlines or helping keep your strategic digital initiatives on course. Check out our case studies and our clients that trust us with their engineering.

Ignacio Falk

I love to learn new things and share what I know. Mentor, Writer, Speaker Member of the local community

@flakolefluk @flakolefluk

Why Every Developer Should Try Elm, + Are We Abandoning JavaScript? with Lindsay Wardell

Lindsay Wardell, Senior Software Engineer at NoRedInk joins Rob Ocel by covering many of the functional programming advantages afforded by Elm. By immersing themselves in the intricacies of languages like Elm, developers can harness its functional approach to bolster application resilience and minimize errors. Lindsay draws parallels with TypeScript's emphasis on strong typing, and how it empowers developers to detect and rectify errors early on, fostering the creation of more maintainable codebases. A pivotal theme emerging from Lindsay's discussions is the importance of adaptability in choosing which languages a developer focuses their energy on. As technology continues to evolve, developers must embrace versatility to remain competitive. Lindsay and Rob Ocel talk about the potential shifts in front-end development paradigms, beyond the dominance of component-based frameworks like React. This underscores the necessity of keeping an open mind and exploring emerging technologies to stay at the forefront of the industry's evolution. Moreover, Lindsay and Rob accentuate the significance of tools such as Nuxt for facilitating seamless backend integration within frameworks like Vue.js. These integrations streamline the development process, enabling developers to concentrate on crafting robust and scalable applications. Their conversations serve as a testament to the ongoing evolution of programming tools, marked by a trend towards simplification and enhanced development efficiency. Download this episode....

Apr 3, 2024

1 min

JavaScriptTypeScript

JSR - The cross-platform package manager for ESM

JSR - The cross-platform package manager for ESM Move over NPM, there’s a new package manager in town. JSR is a new open-source package registry for JavaScript and TypeScript. This particular release has caught my attention, and I’m excited to explore if and where JSR fits into our overflowing ecosystem. Setting the stage The JSR website has a page called Why JSR? I want to explore the _why_ a little bit further. I think that the _why_ points to JSR potentially being the future of the JavaScript ecosystem. NPM and JavaScript modules If you’ve found yourself confused about publishing and consuming packages and modules in the modern ESM era, you’re not alone. When NodeJS was created, there was no standard for JS modules. Node introduced CommonJS modules, and NPM provided a way to publish and consume these modules in our applications. It’s been years now since ES Modules became a standard and we are still in a weird module purgatory with no clear end in sight. JSR represents a fresh start, free from the baggage of the Node and NPM ecosystems. JavaScript runtimes and interoperability New JavaScript runtimes are popping up every year. WinterCG (_Web-interoperable Runtimes Community Group)_ was started to improve interoperability for the various runtimes with some standard APIs. Node has made steps towards this goal, but it might never get all the way there and NPM is coupled pretty tightly to that ecosystem. JSR supports several runtimes (depending on the package). This is a huge opportunity for it to become the package manager for the ecosystem at large. See cross-runtime support section for more details. NPM Compatibility JSR doesn’t end up being a complete departure from NPM since it includes an NPM compatibility layer. The docs highlight some limitations and provide deeper technical details on how this piece works. The simple overview is that you can install and use packages from JSR to a Node/NPM based project. The packages will get added to your package.json and node_modules directory. About the same as any package installed from NPM. JSR Overview At a high level, JSR is very similar to NPM. You can search for packages on the website. You can publish packages to their registry, and you can download packages from it as well. We touched on the two major features that set it apart from NPM: It only supports ESModules, and it has cross-runtime support. In the rest of the article we’ll explore the essentials (package management) and also some other really great features that feel like are bringing the JS package management ecosystem up to speed with our modern workflows. Native TypeScript I have to say I’m not surprised by this feature, considering JSR was developed by the same people behind Deno (a runtime that supports TS natively). It’s a great feature. If you haven’t figured it out yet TypeScript is a big deal and doesn’t seem to be fading away anytime soon. So what exactly does TS support look like in a package manager, though? If your runtime supports TypeScript natively (like Deno) - it can consume the TS files in your package directly. For environments that don’t, it will automatically compile your code to JavaScript and package it with type declaration files (.d.ts). Pretty, stinking, cool. The docs include a page called “about slow types”. It is probably worth a read on its own ,but the TLDR is that JSR will analyze your TS code and penalize you in certain ways if you have some type code that it considers to be slow. On the page, it outlines exactly what these penalties are, as well as what it considers slow types to be. Slow types will also come into play when we get into package scoring later in the article. Packages The docs have a page dedicated to packages. It covers some important stuff like deleting packages, versioning, documentation, and publishing. We’ll touch on some of it with an emphasis on the things that are done differently or better than with NPM. jsr.json file jsr.json is a configuration file that specifies a name, version, and exports of a package. It doesn’t include a list of dependencies like you would have in a package.json file. This is a configuration file for a package to be published to JSR. JSR dependencies are defined in an import map file or a package.json file, depending on the runtime. Adding packages to a project Adding packages to your project will vary depending on your target runtime. Here’s an example of installing it for Deno and NPM using various package managers. For Deno, an import map entry is created. For NPM, it gets installed as an NPM package using the JSR NPM compatibility layer. ` If the runtime has native JSR support, you don’t need to explicitly install packages. You can important them using the jsr: scheme. ` As you can see semantic versioning is supported and works similarly to NPM. Publishing packages If you want to publish a package to JSR, there are many important rules you need to be aware of. I recommend reading “Publishing packages” before moving forward with this. The main things to note are: ESModules only, npm packages are supported, JSR packages are supported, and node APIs are supported. So there aren’t many constraints. You just need to understand how exactly to do these things. IE: how do I use NPM dependencies, how do the imports work, etc? Once you’ve got all that down, you will be ready to publish your first package to JSR 😃 Documentation JSR emphasizes quality package documentation. It’s one of the factors in their package scoring algorithm, which we will discuss shortly. The important parts of a package’s documentation include: * a README.md file * symbol documentation - functions, interfaces, classes, etc * module documentation - docs for each exported module in a package The symbol and module documentation are written using JSDoc. The JSR website generates some nice documentation based on these 3 pieces on your package page. This means you can understand a package's entire public API without ever leaving jsr.io. Browser support The cross-runtime support is amazing, but I was curious where the original JavaScript runtime fit (the browser). According to the documentation: “You can use JSR with any tool that supports ES modules, and either has native support for JSR or supports npm packages using node_modules.” Since modern web browsers support ES modules, I will count this as JSR support. From what I can tell, though, there is one caveat. To include a module on a web page, we need a URL to download it from. Can we publish our package to JSR and use it to load a module via a script tag? According to the JSR usage policy, no. The “Unacceptable use” section states: “It is not acceptable to use JSR as a CDN for serving assets directly to web applications in a browser, except for development purposes.” So, it seems that this is a no-go for now. We will probably need to wait a bit for CDN services like jsdelivr to pull packages from the JSR registry, similar to what they do with NPM currently. Other notable features We’ve covered the most important bits about package management, TS support, NPM compatibility, etc. But there are still a few unique features that add an extra bit of sparkle to JSR. Scoring We mentioned earlier that documentation plays a part in a scoring algorithm. JSR analyzes all of the packages published to its registry and assigns them a score based on certain criteria: documentation, best practices, discoverability, and compatibility. This score is shown with every package listed on the website. You can also add a shiny badge to your README if you’re particularly proud of something. It’s still early on, so it’s likely this will evolve as time goes on. It’s an interesting gimmick, at the very least! Summary I am excited to have a new cross-platform compatible package manager that only supports ESM. As useful as NPM has been all these years, it carries a lot of baggage from “the olden days”. JSR’s native TypeScript support and reliance on modern standards is a breath of fresh air. It feels like I can publish a simple package without much ceremony. I’m excited to release my first package to JSR soon :)...

Apr 12, 2024

6 mins

JSRJavaScript

Testing with Vitest

Vitest is a new testing framework powered by Vite. It's still in development, and some features may not be ready yet, but it's a nice alternative to try and explore. Setup Let's create a new Vite Project! Note: Vitest requires Vite >=v2.7.10 and Node >=v14 to work. ` With our project created, we now need to install all the dependencies required for Vitest to work. ` I added jsdom to be able to mock the DOM API. By default, Vitest will use the configuration from vite.config.ts. I will add one modification to it, and it's svelte specific. Disabling Svelte's hot module replacement when running tests. It should look like the following: ` I'm using the VITEST env variable to differentiate when running tests, but if your configuration is too different, you can use another configuration file for tests. There are a couple of options to do this. * Create a configuration file named vitest.config.ts: it will take precedence when running tests * Using the --config flag: use it like npx vitest --config Writing tests Let's write some tests for the Counter component created by default with our project. ` To write our first set of tests, let's create a file named Counter.spec.ts next to our component. ` Adding the comment line @vitest-environment jsdom at the top of the file will allow us to mock the DOM APIs for all of the tests in the file. However, doing this in every file can be avoided via the config file. We can also make sure that we import describe, it, expect as globals. We do this via the config file. We need to make the types available by adding vitest/globals types in your tsconfig.json file (you can skip this if not using TypeScript). ` ` Our test files don't need to import globals now, and we can remove the jsdom environment setup. ` Commands There are four commands to run from the cli: * dev: run vitest in development mode * related: runs tests for a list of source files * run: run tests once * watch: default mode, same as running vitest. Watches for changes and then reruns the tests. test/suite modifiers There are modifiers for tests and suites that will change how your tests run. * .only will focus on one or more tests, skipping the rest. For suites, it will focus on all the tests in it. * .skip will skip the specified test/suite. * .todo will mark a test or suite to be implemented later. * .concurrently will run contiguous tests marked as concurrent in parallel. For suites, it will run all tests in it in parallel. This modifier can be combined with the previous ones. For example: it.concurrently.todo("do something async") Assertions Vitest ships with chai and jest compatible assertions ` For a list of available assertions, check the API docs. Coverage For coverage reports, we will need to install c8 and run the tests with the --coverage flag ` This will give us a nice coverage report. An output folder coverage will be created at the root of the project. You can specify the desired output type in the configuration file. ` UI You can also run vitest using a UI, which can help you visualize what tests you are running, and their results. Let's install the required package, and run it with the --ui flag. ` I like this interface. It even allows you to read the test code and open it in your editor. More features Vitest comes with many more features, like snapshot testing, mocking, fake timers, and more that you may know from other testing libraries. Migrating to Vitest (from a Vite project using jest) If you are working on a small project or just starting one, you may need to adapt your config file and that would be it. If you are using mock functions, Vitest uses TinySpy and for fake timers, it uses @sinonjs/fake-timers. Check for compatibility. Also, remember to import {vi} from vitest if you will be using it. Another thing that you may need to configure is a setup file. For example, to use jest-dom matchers, we can create a setup file. ` and declare it on our config file. ` Here is an example of the migration of VitePress to Vitest. (There are some ts-config changes but you can see where vitest is added, and the vitest.config.ts file) Final Thoughts Even though Vitest is still in development, it looks very promising, and the fact that they kept the API so similar to Jest, makes the migration very smooth. It also ships with TypeScript support (no external types package). Using the same config file (by default) lets you focus on writing tests very quickly. I look forward to v1.0.0...

Jan 27, 2022

4 mins

JavaScriptTesting

End-to-end type-safety with JSON Schema

End-to-end type-safety with JSON Schema I recently wrote an introduction to JSON Schema post. If you’re unfamiliar with it, check out the post, but TLDR: It’s a schema specification that can be used to define the input and output data for your JSON API. In my post, I highlight many fantastic benefits you can reap from defining schemas for your JSON API. One of the more interesting things you can achieve with your schemas is end-to-end type safety from your backend API to your client application(s). In this post, we will explore how this can be accomplished slightly deeper. Overview The basic idea of what we want to achieve is: * a JSON API server that validates input and output data using JSON Schema * The JSON Schema definitions that our API uses transformed into TypeScript types With those pieces in place, we can achieve type safety on our API server and the consuming client application. The server side is pretty straightforward if you’re using a server like Fastify with already enabled JSON Schema support. This post will focus on the concepts more than the actual implementation details though. Here’s a simple diagram illustrating the high-level concept: We can share the schema and type declaration between the client and server. In that case, we can make a request to an endpoint where we know its type and schema, and assuming the server validates the data against the schema before sending it back to the client, our client can be confident about the type of the response data. Marrying JSON Schema and TypeScript There are a couple of different ways to accomplish this: * Generating types from schema definitions using code generation tools * Creating TypeBox definitions that can infer TypeScript types and be compiled to JSON Schema I recommend considering both and figuring out which would better fit your application and workflows. Like anything else, each has its own set of trade-offs. In my experience, I’ve found TypeBox to be the most compelling if you want to go deep with this pattern. Code generation A couple of different packages are available for generating TS types from JSON Schema definitions. * https://github.com/bcherny/json-schema-to-typescript * https://github.com/vega/ts-json-schema-generator They are CLI tools that you can provide a glob path to where your schema files are located and will generate TS declaration files to a specified output path. You can set up an npm hook or a similar type of script that will generate types for your development environment. TypeBox TypeBox is a JSON Schema type builder. With this approach, instead of json files, we define schemas in code using the TypeBox API. The TypeBox definitions infer to TypeScript types directly, which eliminates the code generation step described above. Here’s a simple example from the documentation of a JSON Schema definition declared with TypeBox: ` This can then be inferred as a TypeScript type: ` Aside from schemas and types, TypeBox can do a lot more to help us on our type-safety journey. We will explore it a bit more in upcoming sections. Sharing schemas between client and server applications Sharing our JSON Schema between our server and client app is the main requirement for end-to-end type-safety. There are a couple of different ways to accomplish this, but the simplest would be to set up our codebase as a monorepo that contains both the server and client app. Some popular options for TypeScript monorepos are: PNPM, Turborepo, and NX. If a monorepo is not an option, you can publish your schema and types as a package that can be installed in both projects. However, this setup would require a lot more maintenance work. Ultimately, as long as you can import your schemas and types from the client and server app, you are in good shape. Server-to-client validation and type-safety For the sake of simplicity, let's focus on data flowing from the server to the client for now. Generally speaking, the concepts also apply in reverse, as long as your JSON API server validates your inputs and outputs. We’ll look at the most basic version of having strongly typed data on the client from a request to our server. Type-safe client requests In our server application, if we validate the /users endpoint with a shared schema - on the client side, when we make the request to the endpoint, we know that the response data is validated using the user schema. As long as we are confident of this fact, we can use the generated type from that schema as the return type on our client fetch call. Here’s some pseudocode: ` Our server endpoint would look something like this: ` You could get creative and build out a map that defines all of your endpoints, their metadata, and schemas, and use the map to define your server endpoints and create an API client. Transforming data over the wire Everything looks stellar, but we can still take our efforts a bit further. To this point, we are still limited to serialized JSON data. If we have a created_at field (number or ISO string) tied to our user, and we want it to be a Date object when we get a hold of it on the client side - additional work and consideration are required. There are some different strategies out there for deserializing JSON data. The great thing about having shared schemas between our client and server is that we can encode our type information in the schema without sending additional metadata from our server to the client. Using format to declare type data In my initial JSON Schema blog post, I touched on the format field of the specification. In our schema, if the actual type of our date is a string in ISO8601 format, we can declare our format to be "date-time". We can use this information on the client to transform the field into a proper Date object. ` Transforming serialized JSON Data This can be a little bit tricky; again, there are many ways to accomplish it. To demonstrate the concept, we’ll use TypeBox to define our schemas as discussed above. TypeBox provides a Transform type that you can use to declare, encode, and decode methods for your schema definition. ` It even provides helpers to statically generate the decoded and encoded types for your schema ` If you declare your decode and encode functions for your schemas, you can then use the TypeBox API to handle decoding the serialized values returned from your JSON API. Here’s what the concept looks like in practice fetching a user from our API: ` Nice. You could use a validation library like Zod to achieve a similar result but here we aren’t actually doing any validation on our client side. That happened on the server. We just know the types based on the schema since both ends share them. On the client, we are just transforming our serialized JSON into what we want it to be in our client application. Summary There are a lot of pieces in play to accomplish end-to-end type safety. With the help of JSON Schema and TypeBox though, it feels like light work for a semi-roll-your-own type of solution. Another great thing about it is that it’s flexible and based on pretty core concepts like a JSON API paired with a TypeScript-based client application. The number of benefits that you can reap from defining JSON Schemas for your APIs is really great. If you’re like me and wanna keep it simple by avoiding GraphQL or other similar tools, this is a great approach....

Apr 17, 2024

6 mins

JSONTypeScript

Animations in Svelte

Animations in Svelte

Modules

svelte/easing

svelte/motion

tweened

svelte/transition

Custom transitions

svelte/animate

extending and reusing animations with transitions

animations from transitions

Extending flip

Final words

Ignacio Falk

You might also like

Why Every Developer Should Try Elm, + Are We Abandoning JavaScript? with Lindsay Wardell

JSR - The cross-platform package manager for ESM

Testing with Vitest

End-to-end type-safety with JSON Schema

You might also like

Why Every Developer Should Try Elm, + Are We Abandoning JavaScript? with Lindsay Wardell

JSR - The cross-platform package manager for ESM

Testing with Vitest

End-to-end type-safety with JSON Schema
